Wide dispensing range with fine control: Covers both micro and larger volume applications with precise, stepwise liquid delivery.
High accuracy and repeatability: Ensures reliable titration results with excellent consistency across multiple runs.
Multi-stage speed adjustment: Offers flexible dispensing speeds to suit different reagents and experimental requirements.
Integrated temperature adaptability: Stable performance across typical laboratory temperature conditions.
Compliant with international standards: Manufactured and tested according to DIN EN ISO 8655 for quality assurance.
External control capability: Can be operated and coordinated with external devices such as stirrers and titration programs.
Compact and space-saving design: Small footprint makes it suitable for crowded laboratory benches.
Lightweight and easy handling: Convenient for daily operation and reduces user fatigue during extended use.
| Volume Range | 0.01mL-99.99mL, Max piston lift is 10mL, resolution is 10μL |
|---|---|
| Volume Accuracy | R=0.2% CV=0.07% |
| Velocity | 16 stages Operating |
| Temperature Range | 10℃ -30℃ |
| Quality Control | DIN EN ISO 8655 |
| Control Type | External control, including the stirrer and the burette program |
| Sizes(W×D×H)(mm) | 225x185x120 |
| Shipping Size(W×D×H)(mm) | 300x240x220 |
| N.W./G.W. (kg) | 1.5/1.7 |
Reagent bottles: Optional (sold separately).
Fill the burette with distilled water and quickly drain it.
Place a container under the outlet and rinse the system by repeatedly filling and draining the burette several times.
Set the valve to recirculation mode, then repeat the rinsing steps.
If necessary, add an appropriate cleaning agent and perform the same procedure.
Remove the tubing, rinse it with deionized water, and reinstall it.
Finally, rinse the entire system with deionized water to ensure no residue remains.
