Thermostatic Incubator Specifications:
| Model | ICB-45 | ICB-65 | ICB-125 | ICB-210 | ICB-45T | ICB-65T | ICB-125T | ICB-210T |
| Capacity(L) | 45 | 65 | 125 | 210 | 45 | 65 | 125 | 210 |
| Circulation Mode | Natural convection |
| Size(WxDxH) | Internal(mm) | 350x350x350 | 400x350x450 | 500x450x550 | 600x580x600 | 350x350x350 | 400x350x450 | 500x450x550 | 600x580x600 |
| External(mm) | 525x480x620 | 575x480x720 | 675x580x820 | 775x710x870 | 525x480x620 | 575x480x720 | 675x580x820 | 775x710x870 |
| Temperature | Range | RT+5~70℃ |
| Fluctuation | ±0.5℃ |
| Resolution | 0.1℃ |
| Uniformity | ±1.5℃ |
| Sensor | PT100 |
| Controller | PID Intelligent |
| Display | Digital LED |
| Timer(min) | 0~9999min (with timing wait function) |
| Material | Internal | High strength galvanized sheet | Mirror stainless steel |
| External | Cold rolled steel electrostatic spraying exterior |
| Shelves(Standard / Max ) | 2 / 7 | 2 / 10 | 2 / 13 | 2 / 14 | 2 / 7 | 2 / 10 | 2 / 13 | 2 / 14 |
| Exhaust hole | Φ35mm top with function of test hole |
| Safety Device | Over temperature Visible & Audible alarm |
| Electricity | Voltage
/Frequency | AC 220/110V, 50/60Hz |
| Consumption | 350W | 450W | 600W | 700W | 350W | 450W | 600W | 700W |
| N.W./G.W. (kg) | 27/40 | 32/45 | 45/60 | 55/70 | 27/40 | 32/45 | 56/70 | 55/70 |
| Shipping Size (WxDxH)(mm) | 595x562x800 | 655x572x885 | 745x662x990 | 855x802x1040 | 595x562x800 | 655x572x885 | 745x662x990 | 855x802x1040 |
| Optional | Spare shelf |
Thermostatic Incubator Features:
Thermostatic incubator utilises a natural convection circulation pattern to ensure uniform internal temperature distribution, resulting in uniform sample heating.
Wide temperature range: Thermostatic incubator has a wide range of temperatures, making it suitable for a variety of biological, medical and laboratory applications.
Equipped with a PID intelligent controller with touch-button settings, it is easy to operate and ensures precise temperature control.
High-strength galvanised or mirror-finish stainless steel interior ensures internal temperature uniformity.
Inner glass door equipped. Double door structure with high-quality glass for easy sample observation, magnetic strip for easy opening and closing, good sealing, and open door power-off function.
Cold rolled steel electrophoretic coating is used on the outside, which is corrosion resistant, has better appearance and texture, and provides long-lasting service life.
LED display with timing waiting function, which is convenient for users to accurately control the incubation time.
Thermostatic incubator is equipped with adjustable shelves to improve space utilisation.
With test hole function, it is convenient to connect with external equipment and increase the flexibility of experiment.
Details of Thermostatic Incubator:
The thermostatic incubator has a reasonable structure, neat and professional appearance, suitable for laboratory environment.
ICB-45T
Transparent see-through door makes it easy to monitor samples without having to open the incubator. Reduces the need to open the door and helps maintain the stability of the internal environment.
Thermostatic incubators are carefully packaged on wooden pallets and protective covers to minimise the risk of damage during transport and handling.
The internal shelving arrangement maximises the use of space and allows multiple samples to be incubated simultaneously.
ICB--65T
Thermostatic incubators are available in a variety of sizes to meet different laboratory needs
