| Time for creating anaerobic state in sample chamber | ≤15 minutes |
| Time for Creating Anaerobic State in Operation Chamber | ≤1.5 hours, O2 content in the operating room ≤ 0.3%
|
| Operating room and sampling room form an anaerobic mode of operation | One click automatic execution |
| Temperature Range | RT+3~60°C | 15~60°C | RT+3~60°C |
| Temperature Stability | <±0.3℃ |
| Temperature Uniformity | <±1℃ |
| Display Resolution | 0.1℃ |
| Anaerobic Grade | Operating room O2 content ≤ 0.1% (without palladium catalyst) |
| Operating room O2 content ≤ 0.01% (with palladium catalyst) |
| Sampling room forms anaerobic (microaerophilic) mode | Vacuum+gas displacement type (99.99% N2 or a mixture of 5% H2 + 10% CO2 + 85% N2) |
| Vacuum+gas displacement type (99.99% N2 or a mixture of 5% O2 + 10% CO2 + 85% N2) |
| Operating room forms anaerobic (microaerophilic) mode | Gas displacement type (99.99% N2 or a mixture of 5% H2 + 10% CO2 + 85% N2)+microflow control |
| Gas displacement type (99.99% N2 or a mixture of 5% O2 + 10% CO2 + 85% N2)+microflow control |
| Sterilization Method | 1500 | 2300 | 1500 |
| O2 Concentration Display Range | 0~21% |
| CO2 Concentration Display Range | 0~20% |
| CO2 Concentration control range | / | 0~20% |
| Humidity Display Range | 0~100% |
| Gas Supply Requirement | Gas purity 99.99%, 0.05Mpa, continuous supply |
| Working Environment Temperature | Applicable ambient temperature: 5~35°C; Optimal ambient temperature: 15~30°C |
| Power supply | AC 220/110V, 50/60Hz |
| Sampling room size (WxDxH)(mm) | 400×330×320 |
| Operating Room Size(WxDxH)(mm) | 910×650×600 |
| Cultivation Room Size(WxDxH)(mm) | 420×300×500 |
| Cultivate Indoor Volume（L) | 63 |
| External Size (WxDxH)(mm) | 1400×730×1370 |
| Packing Size (WxDxH)(mm) | 1540×870×1550 |
| G.W(kg) | 275 | 300 | 275 |
| Standard configuration | Pressure sensor, imported O2 sensor, imported CO2 sensor, temperature sensor, imported humidity sensor, with values displayed on the same screen; USB data recording port; Two sets of 0.22 μ m replaceable HEPA high-efficiency filters. |
| / | Independent CO2 concentration control. |
