Portable Dissolved Oxygen Meter

Model : DO-P610

Measuring Range : (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)%
Resolution : 0.1/0.01 mg/L(ppm), 1/0.1 %
Accuracy : Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L
Response Time : ≤30s (25℃, 90%response)
Residual Current : ≤0.1 mg/L
Sizes(W×D×H)(mm) : 90x160x30mm
The waterproof portable dissolved oxygen meter is housed in an IP57 rated enclosure to ensure durable, rugged performance in outdoor environments.
Availability:

Portable Dissolved Oxygen Meter Specifications:

ModelDO-P610
DOMeasuring Range(0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)%
Resolution0.1/0.01 mg/L(ppm), 1/0.1 %
AccuracyElectrode: ±0.10 mg/L, Instrument: ±0.40 mg/L
Response Time≤30s (25℃, 90%response)
Residual Current≤0.1 mg/L
Temperature Compensation(0 ~ 45)℃ (auto)
Salinity Compensation(0 ~ 45) ppt (auto)
Pressure Compensation(66 ~ 200) kPa (manual)
Automatic CalibrationAir saturated by water, water saturated by air
Electrode TypePolarographic
Other Technical ParametersData Storage200 sets
PowerTwo AA batteries (1.5V x2)
Shipping Size/G.W.(340×270×50)mm/1Kg
Working ConditionsAmbient Temperature5~35 ℃(0.01grade)
Ambient Humidity≤85%
IP gradeIP57 Dustproof and waterproof
Meter Kits1) DO meter
2) DO electrode
3) Temperature electrode
4) DO filling solution
5) Membrane cap
6) Cathode polishing paper
7) Suitcase
External Size90x160x30mm
Shipping Size475x300x55mm
Net /Gross Weight (kg)0.2/1.2

Portable Dissolved Oxygen Meter Features:

  1. Large LCD screen with controllable white backlight.

  2. Built-in microprocessor chip has Intelligent functions such as auto calibration, ATC, data storage, function settings, auto diagnosis, auto power off, and undervoltage prompt, etc.

  3. DO mode has functions of ATC, auto salinity compensation and manual pressure compensation.

  4. New structure polarographic DO electrode can measure temperature, salinity and dissolved oxygen simultaneously, equipped with special DO electrode calibration sleeve, only need 3~5 minutes for polarization.

  5. Combined diaphragm cap makes it extremely convenient to replace the sensitive membrane just by screwing the new cap to the electrode.

  6. Grade IP57 and equipped with suitcase for outdoor purpose.
