Introduction:
The box-type atmosphere furnace is an ideal equipment for atmosphere-protected sintering and
atmosphere restoration in universities, research institutes and industrial and mining enterprises.
It features uniform thermal field, fast heating rate, energy saving and the ability to inject various gases.
Application:
It is widely used for scientific research and small-batch production in enterprise and public
institution, also in the fields of ceramics, metallurgy, electronics, glass, chemical engineering,
machinery, refractory materials, new material development, special materials, building materials
involved in scientific research and teaching in colleges.
Advantage:
1. Appearance Design: It adopts a humanized design, elegant and easy to operate.The outer paint
layer is treated with high-temperature baking process of powder coating, which makes it high
temperature resistant, oxidation resistant, acid and alkali resistant.
2. Structure Design: The shell adopts a double-layer forced air-cooling structure.Cooling is fast,
which can make the external temperature of the furnace close to the room temperature when the
furnace is at high temperature, avoiding the occurrence of accidental injuries.
3. Furnace Chamber Design: It adopts a stepped assembly structure, integrates the laws of
mechanics, effectively ensures the force is evenly applied during the heating process, guarantees
that thermal energy is not easily lost, and prolongs the service life of the furnace chamber.
4. Furnace Chamber Material: The furnace chamber is made of high qualified alumina ceramic fiber,
with features of excellent heat preservation, light weight and high temperature resistance, resistant
to sudden temperature changes, no cracks, no crystallization and on crumbling. There is no worry
about polluting the products being fired.
5. Temperature Control Mode: Standard with intelligent 30 segment PID temperature control.
6 .Temperature Control Safety: The electric furnace adopts integrated circuit and module control
to make the electric furnace work stably, reliably and safely.With protection functions such as bias
temperature protection, over-temperature protection, broken circuit protection, over-current protection, etc.
7. Gas can be injected: All inert gases, such as mixed gases, nitrogen, oxygen, carbon monoxide, argon,.etc.
8. Gas control: The intake end can have 1 or more intake ports. Each intake port is equipped with a ball
valve and is connected to a vacuum gauge. The exhaust end is connected to one exhaust hole, one
vacuum extraction hole. All the holes are equipped with ball valves. The vacuum pump is standard.
9.Sealing Method: The overall surface of furnace door adopts milling and grinding treatment,
and the silicone strip is embedded in the seal, which has strong sealing performance and is easy to open and close.
Specification:
Mode MF-1-12B MF-2-12B MF-6-12B MF-9-12B MF-2-14B MF-4-14B MF-9-14B MF-16-14B MF-2-17B MF-4-17B MF-9-17B MF-16-17B Temp. 1200 ℃ 1400 ℃ 1700 ℃ Capacity (L) 1 4.5 12 36 1 4.5 12 36 1 4.5 12 36 Chamber Size (W×D×H) (mm) 100×100×100 150×200×150 200×300×200 300×400×300 100×100×100 150×200×150 200×300×200 300×400×300 100×100×100 150×200×150 200×300×200 300×400×300 Consumption (kW) 1 2 6 9 2 4 9 16 2 4 9 16 E×terna Size (W×D×H) (mm) 547×490×769 605×630×870 645×740×955 805×875×1060 547×490×839 605×630×900 645×740×980 805×875×1110 547×490×839 605×630×930 645×740×1030 805×875×1250 Shipping Size (W×D×H) (mm) 575×610×955 735×770×1210 770×860×1325 935×1025×1650 670×715×1160 755×775×1260 770×860×1325 1000×1025×1650 670×670×1115 755×775×1240 790×865×1485 1003×1005×1660 G.W. (kg) 114 175 226 351 134 179 227 372 138 221 330 486 Power Suppy 220/110V, 220/110V, 220/110V, 110V-380V, 220/110V, 220/110V, 220/110V, 110V-380V, 220/110V, 220/110V, 110V-380V, 110V-380V,50/60Hz
Item Technical Data Model MF-1-12B;
MF-2-12B;
MF-6-12B;
MF-9-12B
MF-2-14B ;
MF-4-14B;
MF-9-14B;
MF-16-14B
MF-2-17B;
MF-4-17B;
MF-9-17B;
MF-16-17B
Max. Temperature 1200 ℃ 1400 ℃ 1700 ℃ Working Temperature 1100 ℃ 1300 ℃ 1600 ℃ Temperature Control Accuracy ±1℃ Temperature Rising Speed 0-20 ℃/Min, adjustable (suggest ≤10 ℃/Min) Heating Element Resistance wire Silicon carbide rod (SiC rod) Silicon molybdenum rod (MoSi2 rod) Temperature Sensor K type (0-1200 ℃) S type (0-1600 ℃) B type (0-1820 ℃) Heating Mode Three sides heating Two sides heating Two sides heating Chamber Material Alumina ceramic fiber Standard Accessory 1 unit vacuum pump, 1 pair of crucible tongs, 1 pair of special high-temperature gloves Optional Accessory LCD touch screen (50 segment PID temperature control）
